FTP:The FTP (File Transfer Protocol) utility program is commonly used for copying files to and from other computers. These computers may be at the same site or at different sites thousands of miles apart. FTP is a general protocol that works on UNIX systems as well as a variety of other (non-UNIX) systems.
For the purposes of this Web page, the local machine refers to the machine you are initially logged into, the one on which you type the ftp command. The remote machine is the other one, the one that is the argument of the ftp command.
A user interface for the standard File Transfer Protocol for ARPANET, FTP acts as an interpreter on the remote machine. The user may type a number of UNIX-like commands under this interpreter to perform desired actions on the remote machine.
Most operating systems and communication programs now include some form of an FTP utility program, but the commands differ slightly between them. The following explanations and alphabetical list of commands refers to the common FTP utility program as provided on a UNIX machine. Check the documentation for your own machine to determine the comparable commands.
Most computers today include a windows-based type FTP program that is more PC-oriented and does not require full knowledge of these commands.
You can also perform FTP through a browser. For example, bring up Internet Explorer and type in
ftp://yourLoginName@IPaddress
instead of a normal web page URL.
The FTP site of the Computer Science department at CSU requires the user to use sftp, the secure version of FTP. Just type sftp instead of ftp, when you are using FTP in a terminal window.
--------------------------------------------------------------------------------
Getting Started
To connect your local machine to the remote machine, type
ftp machinename
where machinename is the full machine name of the remote machine, e.g., purcell.cs.colostate.edu. If the name of the machine is unknown, you may type
ftp machinennumber
where machinennumber is the net address of the remote machine, e.g., 129.82.45.181. In either case, this command is similar to logging onto the remote machine. If the remote machine has been reached successfully, FTP responds by asking for a loginname and password.
When you enter your own loginname and password for the remote machine, it returns the prompt
ftp>
and permits you access to your own home directory on the remote machine. You should be able to move around in your own directory and to copy files to and from your local machine using the FTP interface commands given on the following page.
--------------------------------------------------------------------------------
Anonymous FTP
At times you may wish to copy files from a remote machine on which you do not have a loginname. This can be done using anonymous FTP.
When the remote machine asks for your loginname, you should type in the word anonymous. Instead of a password, you should enter your own electronic mail address. This allows the remote site to keep records of the anonymous FTP requests.
Once you have been logged in, you are in the anonymous directory for the remote machine. This usually contains a number of public files and directories. Again you should be able to move around in these directories. However, you are only able to copy the files from the remote machine to your own local machine; you are not able to write on the remote machine or to delete any files there.
--------------------------------------------------------------------------------
Common FTP Commands
? to request help or information about the FTP commands
ascii to set the mode of file transfer to ASCII
(this is the default and transmits seven bits per character)
binary to set the mode of file transfer to binary
(the binary mode transmits all eight bits per byte and thus provides less chance of a transmission error and must be used to transmit files other than ASCII files)
bye to exit the FTP environment (same as quit)
cd to change directory on the remote machine
close to terminate a connection with another computer
close brubeck closes the current FTP connection with brubeck,
but still leaves you within the FTP environment.
delete to delete (remove) a file in the current remote directory (same as rm in UNIX)
get to copy one file from the remote machine to the local machine
get ABC DEF copies file ABC in the current remote directory to (or on top of) a file named DEF in your current local directory.
get ABC copies file ABC in the current remote directory to (or on top of) a file with the same name, ABC, in your current local directory.
help to request a list of all available FTP commands
lcd to change directory on your local machine (same as UNIX cd)
ls to list the names of the files in the current remote directory
mkdir to make a new directory within the current remote directory
mget to copy multiple files from the remote machine to the local machine;
you are prompted for a y/n answer before transferring each file
mget * copies all the files in the current remote directory to your current local directory, using the same filenames. Notice the use of the wild card character, *.
mput to copy multiple files from the local machine to the remote machine;
you are prompted for a y/n answer before transferring each file
open to open a connection with another computer
open brubeck opens a new FTP connection with brubeck;
you must enter a username and password for a brubeck account
(unless it is to be an anonymous connection).
put to copy one file from the local machine to the remote machine
pwd to find out the pathname of the current directory on the remote machine
quit to exit the FTP environment (same as bye)
rmdir to to remove (delete) a directory in the current remote directory
--------------------------------------------------------------------------------
Further Information
Many other interface commands are available. Also FTP can be run with different options. Please refer to your manual or the UNIX man page on ftp for more information.
See also the SILS FTP Tutorial
--------------------------------------------------------------------------------
Example Sessions
Examples of two FTP sessions are given on the next two pages. These show the type of interaction you may expect when using the ftp utility.
--------------------------------------------------------------------------------
Example of Anonymous FTP Session
% ftp cs.colorado.edu
Connected to cs.colorado.edu.
220 bruno FTP server (SunOS 4.1) ready.
Name (cs.colorado.edu:yourlogin): anonymous
331 Guest login ok, send ident as password.
Password:
230-This server is courtesy of Sun Microsystems, Inc.
230-
230-The data on this FTP server can be searched and accessed via WAIS, using
230-our Essence semantic indexing system. Users can pick up a copy of the
230-WAIS ".src" file for accessing this service by anonymous FTP from
230-ftp.cs.colorado.edu, in pub/cs/distribs/essence/aftp-cs-colorado-edu.src
230-This file also describes where to get the prototype source code and a
230-paper about this system.
230-
230-
230 Guest login ok, access restrictions apply.
ftp> cd /pub/HPSC
250 CWD command successful.
ftp> ls
200 PORT command successful.
150 ASCII data connection for /bin/ls (128.138.242.10,3133) (0 bytes).
ElementsofAVS.ps.Z
. . .
execsumm_tr.ps.Z
viShortRef.ps.Z
226 ASCII Transfer complete.
418 bytes received in 0.043 seconds (9.5 Kbytes/s)
ftp> get README
200 PORT command successful.
150 ASCII data connection for README (128.138.242.10,3134) (2881 bytes).
226 ASCII Transfer complete.
local: README remote: README
2939 bytes received in 0.066 seconds (43 Kbytes/s)
ftp> bye
221 Goodbye.
% ls
. . .
README
. . .
An FTP session to obtain the HPSC README file from the cs.colorado.edu anonymous ftp directory using a loginname of anonymous and a password of one's own electronic mail address.
--------------------------------------------------------------------------------
Example of Regular FTP Session
% ftp nordsieck.cs.colorado.edu
Connected to nordsieck.cs.colorado.edu.
220 nordsieck FTP server (Version 5.53 Tue Aug 25 10:46:12 MDT 1992) ready.
Name (nordsieck.cs.colorado.edu:yourlogin): yourlogin
331 Password required for yourlogin.
Password:
230 User yourlogin logged in.
ftp> cd HPSC/exercises
250 CWD command successful.
ftp> ls
200 PORT command successful.
550 No files found.
ftp> put tmul.out
200 PORT command successful.
150 Opening ASCII mode data connection for tmul.out.
226 Transfer complete.
local: tmul.out remote: tmul.out
1882 bytes sent in 0.0095 seconds (1.9e+02 Kbytes/s)
ftp> ls
200 PORT command successful.
150 Opening ASCII mode data connection for file list.
tmul.out
226 Transfer complete.
9 bytes received in 0.0021 seconds (4.3 Kbytes/s)
ftp> mput *
mput Makefile? y
200 PORT command successful.
150 Opening ASCII mode data connection for Makefile.
226 Transfer complete.
local: Makefile remote: Makefile
1020 bytes sent in 0.0062 seconds (1.6e+02 Kbytes/s)
mput tmul.out? n
ftp> quit
221 Goodbye.
% ls
. . .
Makefile
tmul.out
. . .
SMTP:This is a list of the SMTP client commands. Useful for manually debugging SMTP mail connections.
SMTP Commands HELO
MAIL FROM:
RCPT TO:
DATA
RSET
SEND FROM:
SOML FROM:
SAML FROM:
VRFY
EXPN
HELP [ ]
NOOP
QUIT
TURN
SMTP Replies 211 System status, or system help reply
214 Help message
220 Service ready
221 Service closing transmission channel
250 Requested mail action okay, completed
251 User not local; will forward to
354 Start mail input; end with .
421 Service not available, closing transmission channel
450 Requested mail action not taken: mailbox unavailable
451 Requested action aborted: local error in processing
452 Requested action not taken: insufficient system storage
500 Syntax error, command unrecognized
501 Syntax error in parameters or arguments
502 Command not implemented
503 Bad sequence of commands
504 Command parameter not implemented
550 Requested action not taken: mailbox unavailable
551 User not local; please try
552 Requested mail action aborted: exceeded storage allocation
553 Requested action not taken: mailbox name not allowed
554 Transaction
failedPOP3 COMMANDS:This is a list of the POP3 client commands. Useful for manually debugging POP3 mail connections.
Basic POP3 Commands (work in all implementations)
Commands in the AUTHORISATION state: USER name
PASS string
QUIT
Commands in the TRANSACTION state: STAT
LIST [msg]
RETR msg
DELE msg
NOOP
RSET
Commands in the UPDATE state: QUIT
Optional POP3 Commands (only work in some implementations)
Commands in the AUTHORISATION state: APOP name digest
Commands in the TRANSACTION state: TOP msg n
UIDL [msg]
POP3 Replies +OK
-ERR
Other than the STAT, LIST, and UIDL commands, only "+OK" and "-ERR" are significant in the reply. Any text supplied in addition to the standard reply may be ignored by the client. However, if supplied, it may be interpreted by teh client for extended functionality.
